Features
Highly automated operation with automatic hot-plate lifting, automatic load application, automatic thickness measurement, automatic temperature control, and automatic furnace door lifting.
Fast and efficient testing with dual heat-flow sensors to improve accuracy; independent temperature control for upper and lower plates.
External oil-bath cooling combined with nitrogen purge for sample drying, reducing environmental dependence and providing a wide temperature range with high stability.
Adaptive measurement for non-flat surface samples; particle sample molding tools are provided, requiring minimal sample preparation.
Software supports thermal conductivity extension accessory mode and offline operation, ensuring flexible experimental workflows.
Fully automatic data acquisition with real-time data monitoring and display, and automatic generation of test reports.
Optional user login with historical record query, supporting customized data storage and export.
High peripheral expandability with a built-in industrial computer, eliminating the need for an external PC; supports connection of mouse, keyboard, printer, and other peripherals.
Excellent industrial design featuring a high-resolution touchscreen, intelligent human–machine interface, and a clean, professional appearance.
Test standards: GB/T 10295-2008, ASTM C518-17, JIS A1412, DIN EN 12667, ISO 8301.
Specifications
| Operating Environment | 5–40°C, <95% RH |
| Plate Temperature Range | −20–100°C |
| Measurable Sample Size | 300 mm × 300 mm (L × W), thickness 5–100 mm |
| Thermal Resistance Range | 0.1–8 m²·K/W |
| Thermal Conductivity Measurement Range | 0.002–1 W/(m·K), expandable to 1–2 W/(m·K) |
| Sample Test Accuracy | ±2% |
| Sample Test Repeatability | 0.5% |
| Maximum Adjustable Contact Load | 1900 N |
| Adjustable Contact Load Accuracy | 10 N (20–200 N), ±5% (200–1900 N) |
